Quality-assured films

Konrad Hornschuch AG

techprofil CoolColors "tp colour" - UNI

Decor Number	Title	Embossing	HBU White	HBU Black
F436-4003	anthrazitgrau STYLO cc	STYLO	approved	approved
F436-4003A	anthrazitgrau STYLO cc	STYLO	approved	approved
F436-5003	anthrazitgrau cc	TPRF	approved	approved
F436-5003A	anthrazitgrau cc	TPRF	approved	approved
F436-5006	stahlblau cc	TPRF	approved	*
F436-5008	weinrot cc	TPRF	approved	*
F436-5013	rubinrot cc	TPRF	approved	approved
F436-5016	maigruen AHP cc	AHP	approved	*
F436-5020	pastellgruen cc	TPRF	approved	approved
F436-5021	tannengruen cc	TPRF	approved	*
F436-5023	schwarzgrau cc	TPRF	approved	approved
F436-5026	brillantblau cc	TPRF	approved	approved
F436-5028	betongrau cc	TPRF	approved	approved
F436-5031	seidengrau cc	TPRF	approved	approved
F436-5033	kieselgrau cc	TPRF	approved	approved
F436-5037	achatgrau cc	TPRF	approved	approved
F436-5038	betongrau cc	TPRF	approved	approved
F436-5043	samtgrau cc	TPRF	approved	approved
F436-5045	steingrau cc	TPRF	approved	approved
F436-5047	quarzgrau cc	TPRF	approved	approved
F436-5048	basaltgrau cc	TPRF	approved	approved
F436-5049	silbergrau cc	TPRF	approved	approved
F436-5050	schiefergrau cc	TPRF	approved	approved
F436-5063	lichtgrau cc	TPRF	approved	approved
F436-5071	schwarzbraun cc	TPRF	approved	approved
F436-6003	anthrazitgrau matt cc	SFTN matt	approved	approved
F436-6003A	anthrazitgrau matt cc	SFTN matt	approved	approved
F436-6013	rubinrot matt cc	SFTN matt	approved	approved
F436-6021	tannengruen matt cc	SFTN matt	approved	*
F436-6023	schwarzgrau matt cc	SFTN matt	approved	approved
F436-6039	silicia matt cc	SFTN matt	approved	approved
F436-6047	quarzgrau matt cc	SFTN matt	approved	approved
F436-6048	basaltgrau matt cc	SFTN matt	approved	approved
F436-6050	schiefergrau matt cc	SFTN matt	approved	approved
F436-6055	s-bronze matt cc	SFTN matt	approved	approved
F436-6064	black matt cc	SFTN matt	approved	approved
F436-6065	umbragrau matt cc	SFTN matt	approved	approved
F436-6066	fenstergrau matt cc	SFTN matt	approved	approved
F436-6071	schwarzbraun matt cc	SFTN matt	approved	approved
F436-7003	anthrazitgrau SFTN cc	SFTN	approved	approved
F436-7003A	anthrazitgrau SFTN cc	SFTN	approved	approved
F436-7023	schwarzgrau SFTN cc	SFTN	approved	approved
F436-7037	achatgrau SFTN cc	SFTN	approved	approved
F436-7047	quarzgrau SFTN cc	SFTN	approved	approved
F436-7048	basaltgrau SFTN cc	SFTN	approved	approved
F436-7049	titanium SFTN cc	SFTN	approved	approved
F436-7050	schiefergrau SFTN cc	SFTN	approved	approved
F436-9003A	anthrazitgrau SFTG cc	SFTG	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil CoolColors "tp print"- Druck

Decor Number	Title	Embossing	HBU White	HBU Black
F436-2001	Macoree cc	TPRF	approved	*
F436-2007	Montana Eiche tabak cc	TPRF	approved	approved
F436-2009	Oregon Pine natur cc	TPRF	approved	approved
F436-2012	Colmar Eiche sepia cc	TPRF	approved	approved
F436-2022	Anegré goldbraun cc	TPRF	approved	approved
F436-2032	Kirsche piemont cc	TPRF	approved	approved
F436-2035	Staufereiche terra cc	TPRF	approved	approved
F436-2036	Staufereiche kolonial cc	TPRF	approved	approved
F436-2044	Kiefer natur cc	TPRF	approved	approved
F436-2046	Vermont Eiche sepia cc	TPRF	approved	approved
F436-2048	Staufereiche mocca cc	TPRF	approved	approved
F436-2060	Sipo cc	TPRF	approved	approved
F436-2075	Eiche mocca cc	TPRF	approved	approved
F436-2076	Eiche kolonial cc	TPRF	approved	approved
F436-2085	Sapeli cc	TPRF	approved	approved
F436-2089	Eiche sepia cc	TPRF	approved	approved
F436-2092	Eiche goldbraun cc	TPRF	approved	approved
F436-3031	Birke rosé cc	MIP	approved	approved
F436-3041	Noce Sorrento nature cc	MIP	approved	approved
F436-3042	Noce Sorrento balsamico cc	MIP	approved	approved
F436-3043	Cherry amaretto cc	MIP	approved	approved
F436-3054	Teak silver grey cc	MIP	approved	approved
F436-3058	Walnuss amaretto cc	HPN	approved	approved
F436-3059	Walnuss terra cc	HPN	approved	approved
F436-3062	Walnuss kolonial cc	HPN	approved	approved
F436-3077	Newcastle Oak khaki cc	HPN	approved	approved
F436-3077A	Newcastle Oak khaki 23 cc	HPN	approved	approved
F436-3078	Asteiche natur cc	HPN	approved	approved
F436-3083	Santana oak rotbraun cc	STYLO	approved	approved
F436-3086	Sheffield Oak grey cc	STYLO	approved	approved
F436-3087	Sheffield Oak brown cc	STYLO	approved	approved
F436-3091	Sheffield Oak kolonial cc	STYLO	approved	approved
F436-3093	Newcastle Oak amaretto cc	HPN	approved	approved
F436-3094	Walnuss rehbraun cc	HPN	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil CoolColors "tp print" - Metallic

Decor Number	Title	Embossing	HBU White	HBU Black
F436-1001	Metbrush aluminium cc	MIP	approved	approved
F436-1002	Metbrush silver cc	MIP	approved	approved
F436-1004	Metbrush platin cc	MIP	approved	approved
F436-1005	Metbrush quarzgrau cc	MIP	approved	approved
F436-1006	Metbrush anthrazitgrau cc	MIP	approved	approved
F436-1007	Metbrush messing cc	MIP	approved	approved
F436-1008	Metbrush titan cc	MIP	approved	approved
F436-1009	Metbrush mocca cc	MIP	approved	approved
F436-1010	Metbrush schoko cc	MIP	approved	approved
F436-1011	Metallic wood mocca cc	STYLO	approved	approved
F436-1012	Alux anthrazit cc	AHN	approved	approved
F436-1014	Alux DB 703 cc	AHN	approved	approved
F436-1014A	Alux DB 703 cc	AHN	approved	approved
F436-1015	Alux weissaluminium cc	AHN	approved	approved
F436-1016	Alux graualuminium cc	AHN	approved	approved
F436-1017	Alux steingrau cc	AHN	approved	approved
F436-1021	x-brush titan cc	Kreuzschliff	approved	approved
F436-1022	x-brush stahlblau cc	Kreuzschliff	approved	*
F436-1024	Alux graphit cc	AHN	approved	approved
F436-1026	x-brush schwarzbraun cc	Kreuzschliff	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil 60 "tp 60" - UNI

Decor Number	Title	Embossing	HBU White	HBU Black
F456-4053	altweiss STYLO cc	STYLO	approved	approved
F456-4054	creme STYLO cc	STYLO	approved	approved
F456-5001	cremeweiss cc	TPRF	approved	approved
F456-5015	beige cc	TPRF	approved	approved
F456-5053	altweiss HOPO cc	HOPO	approved	approved
F456-5054	creme cc	TPRF	approved	approved
F456-5056	hellelfenbein cc	TPRF	approved	approved
F456-5057	brillant weiss AHP cc	AHP	approved	approved
F456-5058	papyrusweiss cc	TPRF	approved	approved
F456-6001	cremeweiss matt cc	SFTN matt	approved	approved
F456-6015	beige matt cc	SFTN matt	approved	approved
F456-6053	altweiss matt cc	SFTN matt	approved	approved
F456-6054	creme matt cc	SFTN matt	approved	approved
F456-7030	verkehrsweiss SFTN cc	SFTN	approved	approved
F456-9004	altweiss cc	TPRF	approved	approved
F456-9005	beige AHP cc	AHP	approved	approved
F456-9016	oxidgrau matt cc	SFTN matt	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil 60 "tp 60" - Druck

Image	Decor Number	Title	Embossing	M30	M20	HBU White	HBU Black
	F456-3081	Sheffield Oak light cc	STYLO			approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil CoolColors Plus "tp colour" - UNI

Decor Number	Title	Embossing	HBU White	HBU Black
F446-4062	jet black STYLO CC+	STYLO	approved	approved
F446-5003	anthrazitgrau CC+	TPRF	approved	approved
F446-5010	schwarzbraun CC+	TPRF	approved	approved
F446-6010	schwarzbraun matt CC+	SFTN matt	approved	approved
F446-6042	American brown matt CC+	SFTN matt	approved	approved
F446-6051	Fango matt CC+	SFTN matt	approved	approved
F446-6062	jet black matt CC+	SFTN matt	approved	approved
F446-7003	anthrazitgrau SFTN CC+	SFTN	approved	approved
F446-7023	schwarzgrau SFTN CC+	SFTN	approved	approved
F446-7041	m-bronze SFTN CC+	SFTN	approved	approved
F446-7052	braun SFTN CC+	SFTN	approved	approved
F446-7062	jet black SFTN CC+	SFTN	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil CoolColors Plus "tp print" - Druck

Decor Number	Title	Embossing	HBU White	HBU Black
F446-1025	goldbronze CC+	MIP	approved	approved
F446-2075	Eiche mocca CC+	TPRF	approved	approved
F446-2076	Eiche kolonial CC+	TPRF	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil Standard "tp colour" - UNI

Decor Number	Title	Embossing	HBU White	HBU Black
F426-1809	white	TPRF	approved	approved
F426-5003	anthrazitgrau	TPRF	approved	approved
F426-5014	blattgruen	TPRF	approved	*
F426-7003	anthrazitgrau SFTN	SFTN	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil Standard "tp print" - Druck

Image	Decor Number	Title	Embossing	M30	M20	HBU White	HBU Black
	F426-2036	Staufereiche kolonial	TPRF			approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

woodec CoolColors

Decor Number	Title	Embossing	HBU White	HBU Black
F470-3001	Turner Oak malt cc	EXT	approved	approved
F470-3002	Sheffield Oak alpine cc	EXT	approved	approved
F470-3003	Sheffield Oak concrete cc	EXT	approved	approved
F470-3004	Turner Oak toffee cc	EXT	approved	approved
F470-3006	Tropea Oak almond cc	EXT	approved	approved
F470-3007	Tropea Oak coffee cc	EXT	approved	approved
F470-9035	Turner Oak amber cc	EXT	approved	approved
F470-9036	Turner Oak walnut cc		approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

mattex CoolColors

Decor Number	Title	Embossing	HBU White	HBU Black
F470-1014	DB 703 cc	ULTRAEXT	approved	approved
F470-1027	brushed gold cc	ULTRAEXT	approved	approved
F470-1028	Shine beige cc	ULTRAEXT	approved	approved
F470-1029	Shine deep bronze cc	ULTRAEXT	approved	approved
F470-1031	Shine grey aluminium cc	ULTRAEXT	approved	approved
F470-1032	Shine white aluminium cc	ULTRAEXT	approved	approved
F470-1033	Shine dark graphite cc	ULTRAEXT	approved	approved
F470-6003	anthrazitgrau cc	ULTRAEXT	approved	approved
F470-6030	verkehrsweiß cc	ULTRAEXT	approved	approved
F470-6047	quarzgrau cc	ULTRAEXT	approved	approved
F470-6048	basaltgrau cc	ULTRAEXT	approved	approved
F470-6065	umbragrau cc	ULTRAEXT	approved	approved
F470-6066	fenstergrau cc	ULTRAEXT	approved	approved
F470-9026	Kitami dark cc	ULTRAEXT	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

mattex CoolColors Plus

Image	Decor Number	Title	Embossing	M30	M20	HBU White	HBU Black
	F476-6055	s-bronze CC+	ULTRAEXT			approved	approved
	F476-6062	jet black CC+	ULTRAEXT			approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil evo CoolColors "tp evo" - UNI

Decor Number	Title	Embossing	HBU White	HBU Black
F466-4053	altweiss STYLO cc	STYLO	approved	approved
F466-4054	creme STYLO cc	STYLO	approved	approved
F466-5001	cremeweiss cc	TPRF	approved	approved
F466-5015	beige cc	TPRF	approved	approved
F466-5053	altweiss HOPO cc	HOPO	approved	approved
F466-5054	creme cc	TPRF	approved	approved
F466-5056	hellelfenbein cc	TPRF	approved	approved
F466-5057	brillant weiss AHP cc	AHP	approved	approved
F466-5058	papyrusweiss cc	TPRF	approved	approved
F466-6001	cremeweiss matt cc	SFTN matt	approved	approved
F466-6015	beige matt cc	SFTN matt	approved	approved
F466-6053	altweiss matt cc	SFTN matt	approved	approved
F466-7030	verkehrsweiss SFTN cc	SFTN	approved	approved
F466-9005	beige AHP cc	AHP	approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

techprofil evo CoolColors "tp evo" - Druck

Image	Decor Number	Title	Embossing	M30	M20	HBU White	HBU Black
	F466-3081	Sheffield Oak light cc	STYLO			approved	approved

Legend

M30 = Climate M checked to 30 GJ/m²
M20 = Climate M checked to 20 GJ/m²

"approved": approval according to the currently valid Technical Annex D (01/2023)

HBU classes according to Technical Annex D until 2022
Heat build-up 1: ≤ 57°C
Heat build-up 2: ≤ 62°C
Heat build-up 3: ≤ 66°C
*: determined value out of RAL tolerance

Publications

Knowledge and information

The latest technical guidelines of the Gütegemeinschaft Kunststoff-Fensterprofilsysteme, consumer magazines relating to PVC windows and many other publications can be found in the Downloads area. RAL-GZ 716 and the Technical Appendix can also be ordered there.

Konrad Hornschuch AG

Legend

Legend

Legend

Legend

Legend

Legend

Legend

Legend

Legend

Legend

Legend

Legend

Legend

Legend

Publications

Knowledge and information

RAL-Gütegemeinschaft Kunststoff-Fensterprofilsysteme e.V.
